| SPECIFICATION |
Title
|
SM
CARD CONNECTOR |
| Part
No |
SMS1.1-1122 |
| MATERIAL
DATA |
Insulation
|
High
temperature thermoplastic UL94V-0 |
| Contacts
|
Phosphor
bronze |
| Shell |
Copper
alloy |
| CONTACT
PLATING DATA |
Under
plating
|
50u"
min. Nickel-plated all over |
Contact
area
|
Gold
plated based on order information |
| Solder
tails area |
Tin-lead
90/10 100u¡¨ min. |
PIN
NUMBER DATA |
| Total
numbers |
22
Pin |
| ELECTRICAL
DATA |
| Current
rating |
0.5
Amps/Contact |
Contact
resistance
|
40
m£[ MAX |
Insulation
resistance
|
1000
M£[ MIN |
| Dielectric
with |
250V
AC |
| |
|
|
|
