| SPECIFICATION |
Title
|
SIM
CARD CONNECTOR |
| Part
No |
SCS2.54-610X |
| MATERIAL
DATA |
Insulation
|
High temperature
thermoplastic UL94V-0 |
| Contacts
|
Copper
alloy |
| CONTACT
PLATING DATA |
Underplate
|
50u"
min. Nickel-plated all over |
Contact
area
|
Gold
plated based on order information |
| Solder
tails area |
Tin-lead
90/10 100u¡¨ min. |
PIN
NUMBER DATA |
| Total
numbers |
2x3~2x6 Pin |
| ELECTRICAL
DATA |
| Current
rating |
0.5
Amps/Contact |
Contact
resistance
|
40
M£[ |
Insulation
resistance
|
1000
M£[ |
| Dielectric
with |
250V
AC |
|
|
|
|
