| SPECIFICATION |
Title
|
Mobile Phone
External FM Antenna, for Sony Ericsson Fast Port type |
| Part
No |
MPFMEA-FP |
Color
|
Iron grey |
|
Function
Four in One |
Mobile Phone External FM Antenna
|
For most peoples who hate listening music with headset, by this
product without headset the mobile phone FM radio still function
well. |
|
Mobile Phone
FM Signal Enhancer |
For most type of mobile phone already embedded FM radio function
inside, but the sound quality is not good enough at some place
which FM signal is poor, this product helps improving signal. |
Standard
3.5mm Headset Adapter
|
For standard 3.5Ø cellular phone headset, i.e. much cheaper,
replacing the much expensive proprietary mobile phone headset. |
Audio out
socket
|
Output to external amplifier
or speakers when stay indoors. |
|
COMPATIBILITY |
Outlet
|
Sony
Ericsson Fast Port |
|
Audio Out |
Standard
3.5mm stereo audio socket |
|
Compatibility |
for Sony
Ericsson mobile phone all Fast Port type with FM radio function |
|
Compatible Models for
Sony Ericsson Mobile Phones: (Fast Port) |
| |
|
C510 |
C510a |
C702 |
C702a |
C901 |
|
C901a |
C902 |
C903 |
C905 |
D750i |
|
F305 |
G502 |
G700 |
G705u |
G900 |
|
J120i |
Jalou |
K330 |
K530i |
K530im |
|
K630i |
K660i |
K750i |
K770i |
K800i |
|
K810i |
K850i |
M600i |
Naite |
P1i |
|
S312 |
T250i |
T303 |
T650i |
T700 |
|
T707 |
T715 |
W200i |
W205 |
W205c |
|
W205i |
W350i |
W380i |
W395 |
W508 |
|
W518a |
W580i |
W595 |
W660i |
W705 |
|
W710i |
W760i |
W810i |
W890i |
W902 |
|
W910i |
W960i |
W980 |
W995 |
Z550i |
|
Z555i |
Z558i |
Z750i |
Z770i |
|
|
|
PACKAGE |
Background
Color
|
Blue |
Package
|
OPP bag
(as below) |
| |
|
Operating Instructions |
|
1. Plug this Mobile External FM Antenna into headset (or
headphone) socket of the compatible mobile phone
with FM radio function.
2. Turn on FM radio function of your mobile phone and enjoy
the program thru your mobile phone speaker, or
3. Plug 3.5mm standard headset (or headphone) or external
speaker wire into the audio out socket of this Mobile External
FM Antenna.
4. Enjoy better signal of FM radio program thru headset (or
headphone) or external speaker.
使用说明 :
1.将此手机外接FM天线插入你具有调频收音机功能的相容手机的耳机口内.
2.启动你手机的调频收音机功能以及扩音器就可以享受调频广播节目, 或
3.将3.5mm标准耳机插头或外接喇叭插头插入此手机外接FM天线的外接喇叭插口内.
4.從耳机或外接喇叭收听较佳收讯的调频节目. |
| |
